What Goes On Behind Touch Screen Monitors?

Gone are the days when our cell phones carried a huge keypad. All the latest gadgets in the market these days are boasting of touch screen monitors. Be it your cell phone or your tablets and readers, everything is touch based. Touch screen monitors have been able to grab the attention of customers and so it comes as no surprise when we see advertisements promoting this feature. Touch screen monitors are available from many manufacturers of monitors, like Dell and others. Are you one of those people who like to know how things happen? Then this article is meant for you. Let us find out what goes on behind these touch screen monitors. How are they able to identify human touch?

What Goes On Behind Touch Screen Monitors?

The answer is not difficult if you can understand the three systems that make it possible – capacitive, acoustic waves and resistive. Let us try analyzing each of them and understand the nuances. The capacitive system works on the principle of charge. A certain amount of electric charge is induced on the touch screen. Whenever a user makes contact with the screen, some of the screen’s charge is passed on to the user, thereby reducing the charge on the screen. The device calculates this reduction in the relative charge and the corresponding information is relayed to the monitors’ driver software.


Surface acoustic waves work on the principle of transducers and reflector. On such monitors two transducers are placed. One is used for sending the signals and the other one is used for receiving. The transducers lie on the x and y plane of the cell phone. Whenever a touch event takes place the transducers are able to intercept it as a wave disturbance and thus localize the change.


The resistive system has two layers, namely, conductive and resistive. Both are separated by space and the whole setup lies protected beneath a scratchproof layer. Whenever a person touches the monitor there is a flow of electric current between the layers that presses them against each other. This current flow is able to identify the touch spot. The location is then transferred to the installed driver that then performs appropriate action.


The three systems differ in terms of their utility and efficiency under varying circumstances. In terms of image clarity, the surface acoustic is known to produce the best pictures followed by capacitive and then resistive. In terms of the touch stimulus, the capacitive system responds to only human touch. Since the resistive system works on the principle of contact amongst its layers, it responds to any kind of touch. A similar thing holds true for acoustic waves that do not respond to stimuli from too hard or too soft objects.


The resistive system is the cheapest with the least clarity and the chances of damage are very high. The best and most expensive is the screen that employs surface acoustic waves. So the next time you go to purchase a device, check out what kind of touch screen monitors the manufacturer offers. With this knowledge at hand you know how to make an intelligent purchase for sure.
